- Out-of-Stock
Asus TUF GAMING Z690-PLUS WIFI D4, Intel Z690, 1700, ATX, 4 DDR4, HDMI, DP, Wi-Fi, 2.5G LAN, PCIe5, RGB, 4x M.2
90MB18V0-M0EAY0
Intel® Z690 (LGA 1700) ATX gaming motherboard 15 DrMOS power stages PCIe® 5.0 DDR4 memory four M.2 slots WiFi 6 and Intel 2.5 Gb Ethernet HDMI® DisplayPort™ USB 3.2 Gen 2x2 Type-C® front USB 3.2 Gen 2 Type C SATA 6 Gbps Thunderbolt™ 4 support and Aura Sync RGB lighting
- Intel® LGA 1700 socket: Ready for 12th Gen Intel Core™ processors
- Enhanced power solution: 14+1 DrMOS six-layer PCB ProCool sockets alloy chokes and durable capacitors for stable power delivery
- Next-gen connectivity: PCIe® 5.0 USB 3.2 Gen2x2 Type-C® front USB 3.2 Gen 2 Type-C Thunderbolt™ 4 header support
- Made for online gaming: WiFi 6 Intel 2.5 Gb Ethernet and TUF LANGuard
- Two-way AI Noise-Cancelation: Reduces background noise from the microphone and audio output for crystal-clear communication in games or video conferences
- Comprehensive cooling: Enlarged VRM heatsink PCH fanless heatsink M.2 heatsinks hybrid fan headers and Fan Xpert 4 utility in Armoury Crate
- Outshine RGB Aura Effect: Stylish edge and PCH lighting design addressable RGB headers and RGB strip header support
Durable. Stable. Reliable.
ASUS TUF GAMING Z690-PLUS WIFI D4 takes all the essential elements of the latest Intel processors and combines them with game-ready features and proven durability. Engineered with military-grade components an upgraded power solution and a comprehensive cooling system this motherboard offers rock-solid and stable performance for marathon gaming. Aesthetically TUF GAMING Z690-PLUS WIFI D4 sports the new TUF Gaming logo and incorporates simple geometric design elements to reflect the dependability and stability that defines the TUF Gaming series.
Rock-Solid Performance
With upgraded power delivery and comprehensive cooling options to drive the 12th Gen Intel Core processors plus support for faster memory and storage TUF GAMING Z690 motherboards are the perfect foundation for your next high-core-count battle rig.
DrMOS
The onboard VRMs feature 14+1 DrMOS power stages that combine high-side and low-side MOSFETs and drivers into a single package delivering the power and efficiency that 12th Gen Intel Core processors demand.The power stages are each rated to handle 80 amperes to provide stable performance for current and future Intel processors.
Easy PC DIY
TUF GAMING motherboards are designed to be easy to set up and configure just the way you want - even for first-time builders. The TUF GAMING Alliance ecosystem makes selecting compatible parts easy while Armoury Crate software provides Fan Xpert 4 and hardware information and offers full full control of Two-Way AI Noise Cancellation RGB lighting and peripheral settings. The TUF GAMING platform gives you the arsenal you need to build and optimize your dream gaming rig without unnecessary complexity.
Build with Confidence
TUF GAMING Alliance is a collaboration between ASUS and trusted PC component brands to ensure compatibility across a wide range of parts such as PC cases power supplies CPU coolers memory kits and more. With new partnerships and components being added regularly the TUF Gaming Alliance will continue to grow even stronger.
Immersive Gaming
TUF GAMING Z690 motherboards provide a high-performance gaming package with a long list of features to improve your experiences including ultrafast networking for smoother online gameplay pristine audio with positional cues for FPS gaming and onboard RGB lighting that syncs with attached accessories to help you create a personalized gaming atmosphere.
Intel WiFi 6
The Intel WiFi 6 module is compatible with the 802.11ax standard and pushes theoretical peak bandwidth up to an incredible 2.4 Gbps. Perhaps more importantly for power users it's optimized for more efficient operation on crowded networks with a lot of competing traffic. Pair your motherboard with ASUS WiFi 6 routers to fully experience the networking potential of WiFi 6. The WiFi antenna designs with four-way positioning that enables better signal reception and a magnetic base to secure the antenna on the top or side of the PC case.
MyASUS
MyASUS offers a variety of support features to help you contact customer service troubleshoot issues and optimize product performance. You can also use MyASUS to enable the WiFi SmartConnect function to automatically connect to the wireless router with the best signal.
- Motherboard Type: Desktop
- Form Factor: ATX
- Socket: Intel 1700
- Chipset: Intel Z690
- DDR Type: DDR4
- CPU Support: Click here for CPU support
- RAM Technology: DDR4 (Dual Channel)
- RAM Slots: 4 x DIMM
- RAM Speeds: Up to 5333(OC)
- Maximum Memory: 128GB
- Graphics: Integrated Graphics*
*Graphics s may vary between CPU types - Graphics Ports: 1 x HDMI
1 x DisplayPort - PCI/PCI Express: 1 x PCIe 5.0 x16
1 x PCIe 3.0 x16
1 x PCIe 3.0 x4
2 x PCIe 3.0 x1 - Storage: 4 x SATA III
2 x M.2 (2242/2260/2280/22110) - PCIe
2 x M.2 (2242/2260/2280) - SATA & PCIe - RAID: "Intel Rapid Storage supports NVMe RAID 0/1/5 SATA RAID 0/1/5/10"
- Wireless: Wi-Fi 6
2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)
Supports 2.4/5GHz frequency band
Bluetooth v5.2 - LAN: 2.5GB LAN
- Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC
- USB Ports Supported: "1 x USB 3.2 Gen 2x2 Type-C (at back)
2 x USB 3.2 Gen2 Type-A (at back)
4 x USB 3.2 Gen1 Type-C (at back)
6 x USB 3.2 Gen1 Type-A (4 at back 2 at mid-board)
4 x USB 2.0 (at mid-board)
1 x USB 3.2 Gen1 connector Type-C at mid-board" - Back Panel I/O Ports: "1 x USB 3.2 Gen2x2 Type-C
2 x USB 3.2 Gen2 ype-A
5 x USB 3.2 Gen1 (4 Type-A 1 Type-C)
1 x DisplayPort
1 x HDMI
1 x Wi-Fi Module
1 x Intel 2.5Gb Ethernet
5 x Audio jacks
1 x Optical S/PDIF out port" - Internal I/O Connectors: 1 x 4-pin CPU Fan
1 x 4-pin CPU OPT Fan
1 x 4-pin AIO Pump
4 x 4-pin Chassis Fan
1 x 24-pin Main
1 x 8-pin +12V
1 x 4-pin +12V
4 x M.2 (Key M)
4 x SATA 6Gb/s
1 x USB 3.2 Gen2 Type-C
1 x USB 3.2 Gen1
2 x USB 2.0 - .: 3 x Addressable Gen2
1 x AURA RGB
1 x Clear CMOS
1 x COM Port
1 x Front Audio
1 x 20-3 pin System Panel
1 x Thunderbolt - Accessories: 2 x SATA 6Gb/s cables
1 x ASUS Wi-Fi moving antenna
2 x M.2 Rubber Packages
1 x M.2 SSD screw package
1 x TUF GAMING sticker
1 x Support DVD
1 x TUF Certification card
1 x User guide - Additional Features: See Overview
- Package Type: Retail
- Package Weight: 1.9700 kg
- Warranty: 3 Years
- M.2 Slot(s): Yes (M.2)
- RGB Lighting: Yes (RGB)
- No. LAN Ports: 1 x LAN
- Max LAN Speed: 2.5GB LAN
- Wi-Fi: Yes (Wi-Fi)
90MB18V0-M0EAY0
