ASUS

Asus ROG STRIX Z690-F GAMING WIFI, Intel Z690, 1700, ATX, 4 DDR5, HDMI, DP, Wi-Fi, 2.5G LAN, PCIe5, RGB, 4x M.2

90MB18M0-M0EAY0
90MB18M0-M0EAY0
£423.16
VAT included
Out-of-Stock



IntelZ690 LGA 1700 ATX motherboard with PCIe5.0 16+1 power stages DDR5 memory support Two-Way AI Noise Cancelation AI Overclocking AI Cooling AI Networking WiFi 6E (802.11ax) Intel2.5 Gb Ethernet four M.2 slots with heatsinks PCIe 4.0 NVMeSSD support M.2 backplate PCIeSlot Q-Release USB 3.2 Gen 2x2 Type-C SATA and Aura Sync RGB lighting


  • Ready for 12th Gen Intel Core Pentium Gold and Celeron processors
  • Optimal Power Solution: 16+1 power stages with 8+8 ProCool II power connectors high-quality alloy chokes and durable capacitors to support multi-core processors
  • Optimized Thermal Design: Integrated I/O cover and VRM heatsinks with high conductivity thermal pad L-shaped heatpipe four onboard M.2 heatsinks and M.2 backplate for the M.2_1 slot
  • High-performance Networking: On-board Intel WiFi 6E (802.11ax) and Intel 2.5 Gb Ethernet with ASUS LANGuard
  • Best Gaming Connectivity: Supports HDMI 2.1 and DisplayPort 1.4 output four M.2 slots as well as USB 3.2 Gen 2x2 Type-C
  • Intelligent Control: ASUS-exclusive AI Overclocking AI Cooling AI Networking and Two-Way AI Noise Cancelation to simplify setup and improve performance
  • DIY Friendly Design:  PCIe Slot Q-Release M.2 Q-Latch ROG Reusable Cable Organizer pre-mounted I/O shield BIOS FlashBack button and Clr CMOS button
  • Unmatched Personalization: ASUS-exclusive Aura Sync RGB lighting including an RGB header and three addressable Gen 2 headers
  • Industry-leading Gaming Audio: ALC4080 with Savitech SV3H712 amplifier along with DTS Sound Unbound and Sonic Studio III
  • Renowned Software: Bundled AIDA64 Extreme 60 days free trial version and intuitive UEFI BIOS dashboard with integrated MemTest86





ROG STRIX Z690-F GAMING WIFI

ROG Strix Z690-F Gaming WiFi offers premium-grade power delivery and cooling to unleash the full force of 12th Gen Intel Core processors. Framerates and load times can be boosted even further by all-new support for DDR5 memory and PCIe 5.0 video cards. Plus ASUS-exclusive intelligent controls help optimize PC settings while onboard WiFi 6E can bring lightning-fast data transfers to an endless variety of scenarios. On top of all that DIY-friendly innovations help simplify the PC building process to get to you up and running smoothly.







Power Design

POWER STAGES

16+1 power stages combine high-side and low-side MOSFETS and drivers into a single package delivering power and efficiency that the latest Intel processors can take full advantage of.





ALLOY CHOKES AND DURABLE CAPACITORS

High-end chokes and durable capacitors are engineered to resist extreme temperatures enabling performance that exceeds industry standards.





8+8 PIN PROCOOL II POWER CONNECTOR

ASUS ProCool II connectors are built to tight s to ensure full contact with power supply cable wiring. A metal sheath improves heat dissipation and low electrical impedance helps prevent hotspots and bolsters reliability.





DIGI+ POWER CONTROL

The Digi+ voltage-regulator module (VRM) is one of the finest in the industry ensuring ultrasmooth and clean power delivery to the CPU.





SIX-LAYER PCB

Multi-layered printed circuit board design quickly dissipates heat around the voltage regulators to improve overall system stability and provide the CPU with more overclocking headroom.








Leading Connectivity

PCIe Performance

With four strategically placed M.2 slots ROG Strix Z690-F Gaming WiFi leverages mighty CPU and chipset bandwidth to deliver lightning-fast PCIe 4.0 data transfers Intel NVM Express RAID and high-capacity drive options that blaze past traditional SATA-based SSDs.





UNDENIABLY ROG STRIX

A specially illuminated acrylic display on the I/O cover gives the illusion that the circuit board is visible beneath an RGB ROG logo. Meanwhile touches of brushed metal throughout the motherboard plus the stitched fabric of the ROG Strix Cable organizer deliver a variety of carefully crafted surface textures. Last but not least a special lighting pattern built into the motherboard finishes off a colorful tour of the ROG worldview.





UEFI BIOS

The renowned ROG UEFI (BIOS) provides everything you need to configure tweak and tune your rig. It offers intelligently simplified options for newcomers to PC DIY as well as more comprehensive features for seasoned veterans.





5-WAY OPTIMIZATION

The renowned ROG UEFI (BIOS) provides everything you need to configure tweak and tune your rig. It offers intelligently simplified options for newcomers to PC DIY as well as more comprehensive features for seasoned veterans.

  • Motherboard Type: Desktop
  • Form Factor: ATX
  • Socket: Intel 1700
  • Chipset: Intel Z690
  • DDR Type: DDR5
  • CPU Support: Click here for CPU support
  • RAM Technology: DDR5 (Dual Channel)
  • RAM Slots: 4 x DIMM
  • RAM Speeds: Up to 6400(OC
  • Maximum Memory: 128GB
  • Graphics: Integrated Graphics*

    *Graphics s may vary between CPU types
  • Graphics Ports: 1 x HDMI
    1 x DisplayPort
  • PCI/PCI Express: 1 x PCIe 5.0 x16
    1 x PCIe 3.0 x16
    1 x PCIe 3.0 x1
  • Storage: 6 x SATA III
    2 x M.2 (2242/2260/2280/22110) - PCIe
    1 x M.2 (2242/2260/2280) - PCIe
    1 x M.2 (2242/2260/2280) - SATA & PCIe
  • RAID: "Intel Rapid Storage supports NVMe RAID 0/1/5 SATA RAID 0/1/5/10"
  • Wireless: Wi-Fi 6E
    2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
    Supports 2.4/5/6GHz frequency band
    Bluetooth v5.2 hardware ready
  • LAN: 2.5GB LAN
  • Audio: ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080
  • USB Ports Supported: "2 x USB 3.2 Gen2x2 Type-C (at back)
    1 x USB 3.2 Gen2 Type-C (at back)
    2 x USB 3.2 Gen2 Type-A (at back)
    6 x USB 3.2 Gen1 Type-A (4 at back 2 at mid-board)
    6 x USB 2.0 (2 at back 4 at mid-board)
    1 x USB 3.2 Gen2x2 Type-C front panel connector"
  • Back Panel I/O Ports: "1 x USB 3.2 Gen2x2 Type-C
    3 x USB 3.2 Gen2 (2 Type-A 1 Type-C)
    4 x USB 3.2 Gen1 Type-A
    2 x USB 2.0
    1 x HDMI
    1 x DisplayPort
    1 x Wi-Fi Module
    1 x Intel I225-V 2.5Gb Ethernet
    5 x Gold-plated audio jacks
    1 x Optical S/PDIF out
    1 x BIOS FlashBack  button
    1 x Clear CMOS button "
  • Internal I/O Connectors: 1 x 4-pin CPU Fan
    1 x 4-pin CPU OPT Fan
    1 x 4-pin AIO Pump
    5 x 4-pin Chassis Fan
    1 x 24-pin Main
    2 x 8-pin +12V
    4 x M.2 (Key M)
    6 x SATA 6Gb/s
    1 x USB 3.2 Gen2x2 Type-C
    1 x USB 3.2 Gen1
    2 x USB 2.0
    3 x AURA Addressable Gen2
  • .: 1 x AURA RGB
    1 x BMC
    1 x CPU Over Voltage jumper
    1 x Front Audio
    1 x SPI TPM (14-1pin)
    1 x 20-3 pin System Panel
    1 x Thermal Sensor
    1 x Thunderbolt
  • Accessories: 4 x SATA 6Gb/s cables
    1 x ASUS 2x2 Dual-Band Wi-Fi moving antennas
    1 x M.2 Q-Latch package
    1 x M.2 Q-Latch package for M.2 backplate
    2 x M.2 Rubber Packages
    1 x ROG key chain
    1 x cable tie
    1 x ROG STRIX stickers
    1 x ROG STRIX thank you card
    1 x Support DVD
    1 x User manual
  • Additional Features: See Overview
  • Package Type: Retail
  • Package Weight: 2.2750 kg
  • Warranty: 3 Years
  • M.2 Slot(s): Yes (M.2)
  • RGB Lighting: Yes (RGB)
  • No. LAN Ports: 1 x LAN
  • Max LAN Speed: 2.5GB LAN
  • Wi-Fi: Yes (Wi-Fi)
