Asrock Z690 TAICHI RAZER Edition, Intel Z690, 1700, ATX, 4 DDR5, HDMI, 2 Thunderbolt, Wi-Fi, 2.5G LAN, PCIe5, Razer Chroma RGB,

• Motherboard Type: Desktop
• Form Factor: ATX
• Socket: Intel 1700
• Chipset: Intel Z690
• DDR Type: DDR5
• CPU Support: Click here for CPU support
• RAM Technology: DDR5 (Dual Channel)
• RAM Slots: 4 x DIMM
• RAM Speeds: Up to 6400+(OC)
• Maximum Memory: 128GB
• Graphics: Integrated Graphics*

  *Graphics s may vary between CPU types
• Graphics Ports: 1 x HDMI
  2 x USB 4.0 Thunderbolt 4 Type-C
• Multi-GPU Support: Supports AMD CrossFire
• PCI/PCI Express: 2 x PCIe 5.0 x16
  1 x PCIe 4.0 x16
  1 x PCIe 3.0 x1
• Storage: 6 x SATA III
  1 x Independent SATA III Connector
  1 x M.2 (2280) - PCIe
  1 x M.2 (2242/2260/2280) - PCIe
  1 x M.2 (2230/2242/2260/2280) - SATA & PCIe
• RAID: "Supports RAID 0 RAID 1 RAID 5 and RAID 10 for SATA storage devices
  Supports RAID 0 RAID 1 and RAID 5 for M.2 NVMe storage devices"
• Wireless: 802.11ax Wi-Fi 6E Module
  Supports IEEE 802.11a/b/g/n/ax
  Supports Dual-Band 2x2 160MHz w/ ext 6GHz band support
  2 antennas - 2 (Transmit) x 2 (Receive) diversity tech
  Supports Bluetooth + High speed class II
  Supports MU-MIMO
  Supports Killer DoubleShot Pro X3
  Supports Intel® Double Connect Technology
• LAN: 2.5GB LAN & GB LAN
• Audio: 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec)
• USB Ports Supported: "2 x Thunderbolt 4 USB Type-C (at back)
  2 x USB 3.2 Gen2 Type-A (at back)
  8 x USB 3.2 Gen1 Type-A (4 at back 4 at mid-board)
  3 x USB 2.0 (at mid-board)
  1 x Independent USB 3.2 Gen1 Type-A connector
  1 x Front Panel Type-C USB 3.2 Gen2x2 Header"
• Back Panel I/O Ports: 2 x Antenna
  1 x HDMI
  1 x Optical SPDIF Out
  2 x USB 3.2 Gen2 Type-A
  2 x USB 4.0 Thunderbolt 4 Type-C
  4 x USB 3.2 Gen1 Type-A
  2 x RJ-45 LAN
  1 x BIOS Flashback Button
  HD Audio Jacks
• Internal I/O Connectors: 1 x SPI TPM
  1 x Power LED and Speaker
  1 x RGB LED
  3 x Addressable LED
  1 x CPU Fan
  2 x CPU/Water Pump Fan
  4 x Chassis/Water Pump Fan
  1 x VRM/Water Pump Fan
  1 x 24 pin ATX
  2 x 8 pin 12V
  1 x Front Audio
  2 x USB 2.0
• .: 1 x Independent USB 3.2 Gen1 Type-A
  2 x USB 3.2 Gen1
  1 x Front Panel Type C USB 3.2 Gen2x2
  1 x Clear CMOS Button
  1 x Dr. Debug with LED
  1 x Power Button with LED
  1 x Reset Button with LED
• Accessories: "Quick Installation Guide Support CD
  4 x SATA Data Cables
  1 x Graphics Card Holder
  1 x Wireless Dongle USB Bracket
  1 x 3010 Cooling Fan w/ Bracket & Screw Package
  1 x 4010 Cooling Fan Bracket & Screw Package
  1 x ASRock WiFi 2.4/5/6 GHz Antenna
  3 x Screws for M.2 Sockets
  1 x Standoff for M.2 Socket"
• Additional Features: See Overview / Video
• Package Type: Retail
• Package Weight: 3.2100 kg
• Warranty: 2 Year Replacement Warranty
• M.2 Slot(s): Yes (M.2)
• RGB Lighting: Yes (RGB)
• No. LAN Ports: 2 x LAN
• Max LAN Speed: 2.5GB LAN
• Wi-Fi: Yes (Wi-Fi)

The COOLEST flagship motherboard ASRock Taichi stands out for its incredible OC performance and premium . Here comes the new version Taichi - Razer Edition

The worlds first motherboard natively integrated with Razer Chroma RGB lighting It is the ultimate control center for all things Chroma RGB and enables universal compatibility with thousands of ARGB components directly into the ecosystem.

1. Plug your ARGB LED strips or devices to any of the 3-pin 5V ARGB headers on the motherboard.
2. Download Razer Synapse from razer.com/synapse then install and login.
3. Use Razer Synapse to access in-depth lighting customization options; and integrate games and applications across your ARGB and Razer Chroma-enabled devices for a truly immersive experience.
