10G Cloud Gateway with 200+ UniFi device / 2,000+ client support, 5 Gbps IPS routing, and redundant NVR storage.
Enhanced computing power and memory for 2x the UniFi device and client capacity of Dream Machine Pro/SE Includes full UniFi application suite for device management 5 Gbps routing with IDS/IPS (1) 10G SFP+, (8) GbE RJ45 LAN ports (1) 10G SFP+, (1) 2.5 GbE RJ45 WAN ports (2) 3.5" NVR HDD bays with RAID data protection Built-in 128 GB SSD for NVR detection recordings UniFi Power Backup ready 1.3" touchscreen
Dimensions 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2")
IDS/IPS Throughput 5 Gbps* *Measured with iPerf3 on a DHCP network. Performance may be reduced with PPPoE depending on ISP implementation.
Power Method (1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz (1) USP-RPS DC input, 11.5V DC, 8.7A
Power Supply AC/DC, internal, 100W
Supported Voltage Range 100—240V AC
Max Power Consumption 100W
Performance Redundant WAN with failover and load balancing WiFi QoS with UniFi APs Application, domain, and country-based QoS Application and device type identification Additional internet failover with LTE Backup Internet quality and outage reporting
Next Generation Security Application-aware firewall rules Signature-based IPS/IDS threat detection Content, country, domain, and ad filtering VLAN/subnet-based traffic segmentation Full stateful firewall
Advanced Networking License-free SD-WAN WireGuard, L2TP and OpenVPN server OpenVPN client OpenVPN and IPsec site-to-site VPN One-click Teleport and Identity VPN Policy-based WAN and VPN routing DHCP relay Customizable DHCP server IGMP proxy IPv6 ISP support
UDM-Pro-Max-UK
