65W Power Budget, with up to 30W for each PoE port
Easy to Use: Supports plug-and-play for instant connectivity and simple configuration for additional features
Centralized Cloud Management via the web or the Omada app
Up to 250m PoE, QoS, PoE Auto Recovery, and Port Isolation for reliable surveillance networking
Automatic Loop Prevention, VLAN, and IGMP Snooping
Fanless design for silent operation
Durable metal casing and desktop/wall mounting design
Software Defined Networking (SDN) with Cloud Access
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface.
Description
Specification
Rackmountable: No
Managed: Yes
Number of Ports: 5
Max RJ45 Transfer Rate: 10/100/1000 Mbps
Interface(s): 5 x 10/100/1000 Mbps RJ45 Ports Ports 1–4 Support 802.3at PoE+ and 802.3af PoE Auto-Negotiation/Auto MDI/MDIX
PoE Ports (RJ45): "Standard: 802.3af PoE and 802.3at PoE+ compliant PoE Ports: 4 ports PoE Budget: 65 W available for all PoE+ ports, 30W max per port PoE Auto Recovery Up to 250m PoE transmission distance"
Switching Capacity: 10 Gbps
Power Supply: DC Power Adapter (Output: 53.5 VDC/ 1.31 A)
