- New
Asus PRIME H610M-K D4 ARGB, Intel H610, 1700, Micro ATX, 2 DDR4, HDMI, PCIe4, 1x M.2
90MB1HN0-M0EAY0
Intel® H610 (LGA 1700) micro-ATX motherboard with DDR4, PCIe 4.0, M.2 slot, Realtek 1 Gb Ethernet, HDMI™, USB 5Gbps, SATA 6 Gbps, Two-Way AI Noise Cancelation, Aura Sync
- Intel® LGA 1700 Socket: Ready for 14th, 13th and 12th Gen Intel® processors
- Ultrafast Connectivity: PCIe 4.0, 32Gbps M.2 slot, Realtek 1 Gb Ethernet and USB 5Gbps support
- Comprehensive Cooling: PCH heatsink and Fan Xpert
- Aura Sync RGB Lighting: Onboard Addressable Gen 2 headers for RGB LED strips, easily synced with Aura Sync-capable hardware
- Two-Way AI Noise Cancelation: Reduces background noise from the microphone and audio output for crystal-clear communication in games or video conferences
Flexibility
Comprehensive controls form the foundation of the ASUS Prime series. The Prime H610 motherboard packs flexible tools to tune every aspect of your system, enabling performance tweaks to perfectly match the way you work to maximize productivity.
Cooler by Design
Prime H610 series feature comprehensive cooling controls that are configurable via Fan Xpert software or via the UEFI BIOS.
Performance
Prime H610 series are built to handle the additional cores and increased bandwidth of 14th, 13th & 12th Generation Intel® processors. ASUS H610 motherboards provide all the fundamentals to boost daily productivity, so your system will be ready for action with stable power, intuitive cooling and flexible transfer options.
Customisation
Prime H610 series add the nuanced details that improve every experience, from exclusive codecs that provide pristine audio quality to intuitive RGB lighting controls that let you customize your system to create a uniquely personal look.
** Click here for full product details **
Description
Specification
- Motherboard Type: Desktop
- Form Factor: Micro ATX
- Socket: Intel 1700
- Chipset: Intel H610
- DDR Type: DDR4
- CPU Support: Click here for CPU support
- RAM Technology: "DDR4 (Dual Channel)
Non-ECC, Un-buffered Memory
Supports Intel Extreme Memory Profile (XMP)" - RAM Slots: 2 x DIMM
- RAM Speeds: Up to 3200 MHz
- Maximum Memory: 64GB
- Graphics: Integrated Graphics
Graphics specifications may vary between CPU types - Graphics Ports: 1 x HDMI
- PCI/PCI Express: 1 x PCIe 4.0 x16 slot (supports x16 mode)
1 x PCIe 3.0 x1 - Storage: 4 x SATA III
1 x M.2 (2242/2260/2280) - PCIe 3.0 x4 - Wireless: -
- LAN: GB LAN
- Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC
- USB Ports Supported: Rear:
2 x USB 5Gbps Type-A
4 x USB 2.0
Front:
2 x USB 5Gbps
1 x USB 2.0 - Back Panel I/O Ports: 2 x USB 5Gbps Type-A
4 x USB 2.0
1 x HDMI
1 x Realtek 1Gb Ethernet
3 x Audio jacks
1 x PS/2 keyboard/mouse combo - Internal I/O Connectors: 1 x 4-pin CPU Fan
1 x 4-pin Chassis Fan
1 x 24-pin Main
1 x 8-pin +12V
1 x M.2 (Key M)
4 x SATA 6Gb/s
1 x USB 5Gbps
1 x USB 2.0
2 x Addressable Gen2
1 x Clear CMOS
1 x COM Port
1 x Front Panel Audio - .: 1 x S/PDIF Out
1 x Speaker
1 x SPI TPM (14-1 pin)
1 x 10-1 pin System Panel - Accessories: 2 x SATA 6Gb/s cables
1 x I/O shield
1 x M.2 anchor
1 x Quick start guide - Additional Features: See Overview
- Package Type: Retail
- Package Weight: 1.0000 kg
- Warranty: 3 Years
- M.2 Slot(s): Yes (M.2)
- No. LAN Ports: 1 x LAN
- Max LAN Speed: GB LAN
90MB1HN0-M0EAY0
