- Out-of-Stock
TP-LINK (TL-SG105S) 5-Port Gigabit Unmanaged Desktop Switch, Steel Case
TL-SG105S
TL-SG105S 5-Port 10/100/1000Mbps Desktop Switch
- 5 10/100/1000Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX
- Green Ethernet technology saves power consumption
- IEEE 802.3x flow control provides reliable data transfer
- Steel housing desktop or wall-mounting design
- Support 802.1p/DSCP QoS and IGMP Snooping function
- Plug and play no configuration needed
What This Product Does
The TP-Link 5-Port 10/100/1000Mbps Desktop Switch provides you an easy way to make the transition to Gigabit Ethernet. Increase the speed of your network server and backbone connections or make Gigabit to the desktop a reality. Plug and Play design with no configuration required makes the product easy to use. Moreover TL-SG105S adopts lower power consumption design. With the innovative energy-efficient technology the TL-SG105S can save power consumption making it an eco-friendly solution for your home or office network.
Gigabit Switch
Featured with 5 10/100/1000Mbps ports TL-SG105S greatly expands your network capacity enabling instant large files transferring. So power users in the home office workgroup or creative production environment can now move large bandwidth-intensive files faster. Transfer graphics CGI CAD or multimedia files across the network instantly.
Go Green With Your Ethernet
You now have the choice to go green when upgrading to a gigabit network! This new generation TL-SG105S 5-Port 10/100/1000Mbps Desktop Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.
Traffic Optimization
802.1p and DSCP QoS enable smooth latency-sensitive traffic such as voice and video and IGMP Snooping optimizes the Multicast data stream.
Easy to use
The auto features of this gigabit switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminate the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (either 10 100 or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance. Moreover fanless design ensures quiet operation.
- Rackmountable: No
- Managed: No
- Number of Ports: 5
- RJ45 Data Transfer Rate: 10/100/1000 Mbps
- Interface(s): "5 10/100/1000Mbps Auto-Negotiation Auto-MDI/MDIX Ports"
- PoE Ports (RJ45): =
- Standards and Protocols: "IEEE 802.3i/802.3u/ 802.3ab/802.3x IEEE 802.1p"
- LED: System Power
Link/Act indicators per port built into each RJ-45 port - Power Supply: Output: 5VDC / 0.6A
- Dimensions: 99.8 x 98 x 25 mm
- Transfer Method: Store and forward
- Mac Address Table: 2K
- Packet Forwarding Rate: 7.4Mpps
- Jumbo Frame: 16KB
- Advanced Functions: Green Technology
802.3x Flow Control
802.1p/DSCP QoS
IGMP Snooping
Fanless - Quality of Service: 802.1P/DSCP QoS
- Environment: "Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5%~95% non-condensing" - Package Contents: 5-Port 10/100/1000Mbps Desktop Switch
Power Adapter
Installation Guide
Rubber Feet - Package Type: Retail
- Package Weight: 0.0000 kg
- Warranty: Limited Lifetime
- POE: No
TL-SG105S
