TP-LINK (TL-SG1210P) 10-Port GB Desktop Switch, 9 RJ45 + 1 SFP Port, 8-Port PoE+, Metal Casing
TL-SG1210P
10-Port Gigabit Desktop Switch with 8-Port PoE+
- 9 10/100/1000Mbps RJ45 ports 1 Gigabit SFP port
- With 8 PoE+ ports transfers data and power on one single cable
- Working with IEEE 802.3af/at compliant PDs expands home and office network
- 802.1p/DSCP QoS enable smooth latency-sensitive traffic
- High PoE power budget with up to 30W for each PoE port and 63W for all PoE ports
- Easy to use with no configuration and installation needed
PoE Switches for Your Ultra Convenience
Surveillance
Work with IP Cameras
Conference Call
Work with IP Phones
Wi-Fi Coverage
Work with Omada EAPs
Power over Ethernet
Port 1-8 of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af/at compliant Powered Devices (PDs).
Intelligent Power Management
When total power consumption excels 63W the intelligent power management will cut the lower priority port power off to ensure the high priority port’s power supply and protect the device from power overload operation.
Advanced Functions for Higher Performance
Qos For Fluent Online Experience
Administrators can designate the priority of traffic based on QoS for example to ensure that voice and video applications remain clear and lag-free.
IGMP Snoopingn Traffic Optimization for IPTV
IGMP Snooping optimizes multimedia traffic delivery to ensure a better network experience especially for applications like IPTV.
Sturdy Metal Casing
Sturdy compact metal casing with desktop/wall-mounting design to meet your needs in any environment. Besides fanless design ensures quiet operation.
- Rackmountable: No
- Managed: No
- Number of Ports: 10
- RJ45 Data Transfer Rate: 10/100/1000 Mbps
- Interface(s): 8 x 10/100/1000Mbps RJ45 Ports
1 x 10/100/1000Mbps RJ45 Port
1 x Gigabit SFP Slot - PoE Ports (RJ45): 8 PoE+ 10/100Mbps RJ45 ports
Standard: 802.3at/802.3af compliant
PoE Ports: Port1- Port 8
PoE Power Budget: 63W - Bandwidth: 20 Gbps
- Power Supply: External Power Adapter(Output: 53.5VDC / 1.31A)
- Dimensions: 209 x 126 x 26 mm
- Transfer Method: Store-And-Forward
- Mac Address Table: 4K
- Advanced Functions: Compatible With IEEE 802.3af/at Compliant PDs
EEE802.3x Flow Control
802.1p/DSCP QoS
IGMP Snooping - Security: Physical Security Lock
- Environment: Operating Temperature: 0°C~40°C (32°F~122°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5%~90% non-condensing - Package Contents: TL-SG1210P
Power Adapter
Installation Guide - Package Type: Retail
- Package Weight: 0.2750 kg
- Warranty: Lifetime Warranty
- POE: Yes
TL-SG1210P
