TP-LINK (TL-SF1024D) 24-Port 10/100 Unmanaged Desktop/Rackmount Switch, Steel Case
TL-SF1024D
Highlights:
- 24 10/100M RJ45 ports.
- Supports MAC address self-learning and auto MDI/MDIX.
- Standard 13-inch steel case.
What This Product Does
The TL-SF1024D Fast Ethernet Switch provides you with a high-performance low-cost easy-to-use seamless and standard upgrade to improve old network to 1000Mbps network. All 24 ports support auto MDI/MDIX no need to worry about the cable type simply plug and play. Moreover with the innovative energy-efficient technology the TL-SF1024D can save up to 75%* of the power consumption and 80% of the packaging material can be recycled making it an eco-friendly solution for your business network.
High Performance
The metal case design combined with a safety certified internal power supply make the Switch the most robust product which is very cost-effective for a less than 24 user environment. Featuring non-blocking switching architecture TL-SF1024D forwards and filters packets at full wire-speed for maximum throughput. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the traffic congestion and make TL-SF1024D work reliably.
TP-LINK Green Technology
This new generation The TL-SF1024D Fast Ethernet Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network. It also complies with the EU'S RoHS prohibiting the use of certain hazardous materials. Besides 70% of the packaging material can be recycled.
Easy to Use
The auto features of this fast ethernet switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10 100 or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance.
- Rackmountable: Yes
- Managed: No
- Number of Ports: 24
- RJ45 Data Transfer Rate: 10/100 Mbps
- Interface(s): 24 x 10/100Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX)
- Bandwidth: 4.8Gbps
- Standards and Protocols: "IEEE802.3 802.3u 802.3x CSMA/CD TCP/IP"
- LED: "Power Link/Act 100Mbps"
- Power Supply: "100-240VAC 50/60Hz"
- Dimensions: 11.6 x 7.1 x 1.7 in. (294 x 180 x 44 mm)
- Transfer Method: Store-and-Forward
- Mac Address Table: 8k
- Port Forwarding: 10BASE-T: 14880pps/port
100BASE-TX: 148800pps/port - Advanced Functions: Wire-speed Performance
MAC Address Auto-Learning and Auto-aging
IEEE802.3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode - Environment: Operating Temperature: 0C~40C (32F~104F)
Storage Temperature: -40C~70C (-40F~158F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing - Package Contents: 24-Port 10/100Mbps Desktop/Rackmount Switch
Power Cord
Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 1.9300 kg
- Warranty: Limited Lifetime
- POE: No
TL-SF1024D
