TP-LINK

TP-LINK (TL-SF1009P) 9-Port 10/100 Unmanaged Desktop Switch, 8 Port PoE+, Steel Case

TL-SF1009P
TL-SF1009P
85 Items
£52.85
VAT included

Order now and receive it...

✔ between 24 Apr and 25 Apr   with  Standard Delivery - Free over £65

✔ 21 Apr   with  Next Working Day - Order Before 1pm Mon-Fri (not guaranteed)


9-Port 10/100Mbps Desktop Switch with 8-Port PoE+

  • 9x 10/100 Mbps RJ45 ports
  • 8x PoE+ ports transfer data and power on individual cables
  • Works with IEEE 802.3af/at compliant PDs
  • Supports PoE Power up to 30 W for each PoE port
  • Supports PoE Power up to 65 W for 8 PoE ports*
  • Up to 250 m data and power transmitting range under Extend Mode**
  • Priority Mode ensures high priority of ports 1–2 to guarantee the quality of sensitive application
  • Isolation Mode allows one-click client traffic separation for higher security and performance
  • Plug and play with no configuration required




Professional 9-Port Switch with 8-Port PoE+ (65 W Budget) for Numerous Applications

Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 65 W PoE power budget* for the 8× PoE+ ports opens up a wide range of applications such as surveillance for offices dormitories and small businesses. It is fully compatible with IP cameras access points IP phones computers printers and more.





Ideal for IP Surveillance - Up to 250 m Transmissions

With extend mode the PoE transmission distance reaches up to 250 m**—perfect for IP Camera deployment in large areas.

**The speed of the ports in extend mode will downgrade to 10 Mbps. The actual transmission distance may vary due to power consumption of PoE-powered devices or the cable quality and type.





Ideal for IP Surveillance - Higher Performance and Security

Priority Mode and Isolation Mode make surveillance smoother and safer.





Priority Video Quality Guaranteed

Quality of sensitive applications like video monitoring in critical business areas is guaranteed by offering higher priority options for ports 1–2 when one-touch Priority Mode is on.






Isolation Mode Button

One-Click Traffic Separation for Ports 1-8
With one click Isolation Mode easily divides traffic for ports 1–8 to avoid snooping and tampering. This enables the switch to isolate broadcast storm improving LAN security and data transmission.





Intelligent Power Management

When total power consumption exceeds 65 W the intelligent power management will cut the lower priority port power. This ensures the high priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.





Durable Metal Casing

The interior components of TL-SF1009P are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests TL-SF1009P delivers switching performance you can depend on.




*PoE budget calculations are based on laboratory testing. Actual PoE power budget is not guaranteed and will vary as a result of client limitations and environmental factors.

**The speed of the ports in extend mode will downgrade to 10 Mbps. The actual transmission distance may vary due to power consumption of PoE-powered devices or the cable quality and type.



  • Rackmountable: No
  • Managed: No
  • Number of Ports: 9
  • RJ45 Data Transfer Rate: 10/100 Mbps
  • Interface(s): 9 x 10/100 Mbps RJ45 (8x 802.3af/at PoE+)
    AUTO Negotiation
    AUTO MDI/MDIX
  • PoE Ports (RJ45): Standard: 802.3 af/at compliant
    PoE Ports: Ports 1–8
    Power Supply: 65 W
  • Switching Capacity: 1.8 Gbps
  • Power Supply: External Power Adapter (Output: 53.5VDC / 1.31A)
  • Dimensions: 171 x 98 x 27 mm
  • Transfer Method: Store-And-Forward
  • Mac Address Table: 2K
  • Packet Forwarding Rate: 1.3392 Mpps
  • Jumbo Frame: 2 KB
  • Advanced Functions: "Compatible With IEEE 802.3af/at Compliant PDs
    Mac Address Auto-Learning and Auto-Aging
    IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure for Half-Duplex Mode
    Priority Mode Button (Ports 1–2)
    Isolation Mode Button (Ports 1–8)
    Extend Mode Button (Ports 1–4 and Ports 1–8 Up to 250 m PoE power supply and data transmission"
  • Security: Physical Security Lock
  • Environment: Operating Temperature: 0–40C (32–104F)
    Storage Temperature: -40–70C (-40–158F)
    Operating Humidity: 10–90% RH non-condensing
    Storage Humidity: 5–90% RH non-condensing
  • Package Contents: TL-SF1009P
    Power Adapter
    Installation Guide
  • Package Type: Retail
  • Package Weight: 0.9950 kg
  • Warranty: Limited Lifetime
  • POE: Yes
TL-SF1009P
85 Items
