TP-LINK
  • TP-LINK

TP-LINK (EAP660 HD) AX3600 Dual Band Wireless Multi-Gigabit Ceiling Mount Access Point, PoE+, 2.5GB LAN, MU-MIMO, Free Software

£225.70
VAT included
Quantity
Add to wishlist
Out-of-Stock


AX3600 Wireless Dual Band Multi-Gigabit Ceiling Mount Access Point


  • Ultra-Fast Wi-Fi 6 Speeds: Simultaneous 1148 Mbps on 2.4 GHz and 2402 Mbps on 5 GHz totals 3550 Mbps Wi-Fi speeds.
  • High-Density Connectivity: 4x increased capacity to connect more devices simultaneously.
  • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP) Centralized Cloud Management and Intelligent Monitoring.
  • Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
  • 2.5G Port: A 2.5 Gbps Ethernet port boosts total internet throughput.
  • Seamless Roaming: Even video streams and voice calls are unaffected as users move between locations.
  • PoE+ Support: Supports Power over Ethernet (802.3at) for convenient deployment and installation.
  • Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher etc.) and abundant wireless security technologies.





High-Density Connectivity with 4x Increased Capacity

OFDMA and Uplink & Downlink MU-MIMO increase network capacity by up to 4x versus Wi-Fi 5 (802.11ac) in high-density environments to connect more devices simultaneously. Leverage multi-user capabilities and upgrade your business like never before.





Blazing Fast Speed with 8 Spatial Streams

The Omada Wi-Fi 6 Access Point features the latest 802.11ax technologies like 1024 QAM and Long OFDM Symbol which allows the EAP to boost overall speeds up to 3550 Mbps (2402 Mbps on a 5 GHz band and 1148 Mbps on a 2.4 GHz band). With 8 spatial streams multi-user throughput is incredibly increased to drive more applications.





Omada SDN-Smarter Cloud Solution for Business Networking

Omada Software Defined Networking (SDN) platform integrates network devices including access points switches and gateways guaranteeing powerful business network with higher efficiency higher security and higher reliability.





Optimized Wired Performance with 2.5 GE PoE+ Port

Armed with a 2.5 Gigabit Ethernet Port the EAP660 HD delivers exceptional multi-gigabit performance to support the insatiable demand for better and faster Wi-Fi. Compatibility with standard 802.3at PoE+ is ideal for flexible deployment.





Seamless Roaming

802.11k/v roaming switches clients automatically to the AP with the optimal signal with a seamless transition when moving. This allows sensitive applications like VoIP and video conferences to go uninterrupted.






Boost Network Efficiency in All Aspects With Rich Advanced Features

Band Steering
Automatically moves dual band devices onto the wider 5GHz band for faster connections.

Load Balance
ensures large numbers of users have smooth network experiences in high-density business networks

Airtime Fairness
Increases average network throughput in heavily congested environments





Secure Guest Network with Facebook Wi-Fi and SMS Login

Guest Network provides elevated secure access to guests sharing your Wi-Fi network with captive portal helping maintain only authorized guests to use the network. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and power up your business.





  • Primary Function: Access Point
  • Access Point Mode: Yes (Access Point Mode)
  • Dual Band: Yes (Dual Band)
  • Max Wireless Transfer Rate: 2402 Mbps
  • Max Wired Transfer Rate: 10/100/1000/2500 Mbps
  • Interface(s): 1 x 2.5 Gbps Ethernet Port (supports IEEE802.3at PoE)
  • Wireless Standards: IEEE 802.11ax/ac/n/g/b/a
  • Antenna: 2.4 GHz: 4 x 5 dBi
    5 GHz: 4 x 6 dBi
  • Button(s): Reset
  • Power Supply: 802.3at PoE
    12 V DC
  • Power Consumption: 18.5 W
  • Dimensions (W x D x H): 243 x 243 x 64 mm
  • Weatherproof: No
  • Frequency: 5GHz: Up to 2402Mbps
    2.4GHz: Up to 1148Mbps
  • Wireless Functions: "1024-QAM
    4x Longer OFDM Symbol
    OFDMA
    Multiple SSIDs (Up to 16 SSIDs 8 for each band)
    Enable/Disable Wireless Radio
    Automatic Channel Assignment
    Transmit Power Control (Adjust Transmit Power on dBm)
    QoS(WMM)
    MU-MIMO
    Seamless Roaming"
  • .: Band Steering
    Load Balance
    Airtime Fairness
    Beamforming
    Rate Limit
    Reboot Schedule
    Wireless Schedule
    Wireless Statistics based on SSID/AP/Client
  • Wireless Security: "Captive Portal Authentication
    Access Control
    Wireless Mac Address Filtering
    Wireless Isolation Between Clients
    SSID to VLAN Mapping
    Rogue AP Detection
    802.1X Support
    WEP WPA-Personal/Enterprise WPA2-Personal/Enterprise WPA3-Personal/Enterprise"
  • Quality of Service: QoS(WMM)
  • Management: "Omada App
    Omada Cloud-Based Controller
    Omada Hardware & Software Controller
    Cloud Access
    Email Alerts
    LED ON/OFF Control
    MAC Access Control
    SNMP v1 v2c v3
    Local/Remote Syslog
    SSH
    HTTP/HTTPS
    L3
    Multi-site Management
    Management VLAN"
  • Advanced Functions: See Overview/ Video
  • Environment (°C): Operating Temperature: 0–40 C (32–104 F)
    Storage Temperature: -40–70 C (-40–158 F)
    Operating Humidity: 10–90% RH non-condensing
    Storage Humidity: 5–90% RH non-condensing
  • Package Contents: EAP660 HD
    Power Adapter
    Ceiling/Wall Mounting Kits
    Installation Guide
  • Package Type: Retail
  • Package Weight: 1.4000 kg
  • Warranty: Limited Lifetime
EAP660 HD
