Fractal Design Prisma AL-18 ARGB PWM 18cm Case Fans x2, 7 Blades, Long Life Sleeve Bearing, 300-1200 RPM, White
FD-FAN-PRI-AL18-PWM-WT
Super-sized airflow
The Prisma AL-18 is a powerful 180 mm ARGB fan that packs a mean punch in the airflow department. Massive blades, stout 38 mm thickness, and wide 300-1200 RPM range with PWM control allow the AL-18 to yield remarkably high airflow while remaining remarkably quiet.
- Massive 180 x 38 mm RGB fan that yields remarkably high airflow while remaining very quiet
- Twelve individually addressable hub-mounted RGB LEDs
- Specially designed fan blades and outer ring produce an exceptionally uniform glow
- LLS (Long Life Sleeve) bearings provide silent operation with a long lifespan
- Integrated vibration-damping corners made from high-quality synthetic rubber
- Trip Wire technology introduces a micro-turbulent layer for enhanced blade efficiency
- Aerodynamic stator struts with embedded wiring reduce noise and turbulence
- Chainable RGB cables simplify wiring and make the most of available connections
- PWM control with a wide 300-1200 RPM speed range ideal for radiators
- Black sleeved power cables offer an extra touch of style
- ASUS AURA, Gigabyte Fusion, MSI Mystic Light and ASRock Polychrome support
- Adjust R1 RGB controller (sold separately) enables physical control of colors and effects
- Fits standard 180 mm fan mounts with 165 x 165 mm screw hole pattern
Description
Specification
- Type: 18cm Case Fan
- Fan Connector(s): 4-pin
- Installation: Screws
Chainable RGB cables - #Hide#LED Lighting: Yes
- Colour: White
- LED Lighting: "12 individually addressable hub-mounted RGB LEDs
Blades and outer ring produce an exceptionally uniform glow
Chainable RGB cables simplify wiring
Adjust R1 RGB controller (sold separately) enables physical control of colors/effects
ASUS AURA, Gigabyte Fusion, MSI Mystic Light and ASRock Polychrome support" - Material: Vibration-damping corners made from high-quality synthetic rubber
- Weight: 521 g
- Fan Dimensions: 180 x 180 x 38 mm
- Fan Controller: PWM
- Rotation Speed: 300 - 1200 RPM
- Fan Bearing: Long Life Sleeve bearing
- Air Flow: 43.1 – 146.8 CFM
- Noise level: 14.9 - 37.4 dB(A)
- Power: Fan input power: 4.2W at 12VDC
Fan max input current: 0.35A
Fan input voltage: 12V
Minimum startup voltage: 6V
LED rated voltage: 5V
LED rated current: 0.6A
LED Rated input power: 3.0W - Additional Features: See Overview
- MTBF: "90,000 hours"
- Package Contents: Prisma AL-18 180 mm fan
4 x fan screws
4 x extra-long radiator screws - Package Type: Retail
- Package Weight: 0.0000 kg
- Warranty: 3 Years
